In Android 17, apps targeting SDK 37 or higher will receive a new implementation of MessageQueue where the implementation is lock-free. The new implementation improves performance and reduces missed frames, but may break clients that reflect on MessageQueue private fields and methods. To learn more about the behavior change and how you can mitigate impact, check out the MessageQueue behavior change documentation. This technical blog post provides an overview of the MessageQueue rearchitecture and how you can analyze lock contention issues using Perfetto.

The Looper drives the UI thread of every Android application. It pulls work from a MessageQueue, dispatches it to a Handler, and repeats. For two decades, MessageQueue used a single monitor lock (i.e. a synchronized code block) to protect its state.

Android 17 introduces a significant update to this component: a lock-free implementation named DeliQueue.

This post explains how locks affect UI performance, how to analyze these issues with Perfetto, and the specific algorithms and optimizations used to improve the Android main thread.

The problem: Lock Contention and Priority Inversion

The legacy MessageQueue functioned as a priority queue protected by a single lock. If a background thread posts a message while the main thread performs queue maintenance, the background thread blocks the main thread.

When two or more threads are competing for exclusive use of the same lock, this is called Lock contention. This contention can cause Priority Inversion, leading to UI jank and other performance problems.

Priority inversion can happen when a high-priority thread (like the UI thread) is made to wait for a low-priority thread. Consider this sequence:

1. A low priority background thread acquires the MessageQueue lock to post the result of work that it did.

2. A medium priority thread becomes runnable and the Kernel’s scheduler allocates it CPU time, preempting the low priority thread.

3. The high priority UI thread finishes its current task and attempts to read from the queue, but is blocked because the low priority thread holds the lock.

The low-priority thread blocks the UI thread, and the medium-priority work delays it further.

Analyzing contention with Perfetto

You can diagnose these issues using Perfetto. In a standard trace, a thread blocked on a monitor lock enters the sleeping state, and Perfetto shows a slice indicating the lock owner.

When you query trace data, look for slices named “monitor contention with …” followed by the name of the thread that owns the lock and the code site where the lock was acquired.

Case study: Launcher jank

To illustrate, let’s analyze a trace where a user experienced jank while navigating home on a Pixel phone immediately after taking a photo in the camera app. Below we see a screenshot of Perfetto showing the events leading up to the missed frame:

• Symptom: The Launcher main thread missed its frame deadline. It blocked for 18ms, which exceeds the 16ms deadline required for 60Hz rendering.

• Diagnosis: Perfetto showed the main thread blocked on the MessageQueue lock. A “BackgroundExecutor” thread owned the lock.

• Root Cause: The BackgroundExecutor runs at Process.THREAD_PRIORITY_BACKGROUND (very low priority). It performed a non-urgent task (checking app usage limits). Simultaneously, medium priority threads were using CPU time to process data from the camera. The OS scheduler preempted the BackgroundExecutor thread to run the camera threads.

This sequence caused the Launcher’s UI thread (high priority) to become indirectly blocked by the camera worker thread (medium priority), which was keeping the Launcher’s background thread (low priority) from releasing the lock.

Querying traces with PerfettoSQL

You can use PerfettoSQL to query trace data for specific patterns. This is useful if you have a large bank of traces from user devices or tests, and you’re searching for specific traces that demonstrate a problem.

For example, this query finds MessageQueue contention coincident with dropped frames (jank):

INCLUDE PERFETTO MODULE android.monitor_contention;
INCLUDE PERFETTO MODULE android.frames.jank_type;

SELECT
  process_name,
  -- Convert duration from nanoseconds to milliseconds
  SUM(dur) / 1000000 AS sum_dur_ms,
  COUNT(*) AS count_contention
FROM android_monitor_contention
WHERE is_blocked_thread_main
AND short_blocked_method LIKE "%MessageQueue%"

-- Only look at app processes that had jank
AND upid IN (
  SELECT DISTINCT(upid)
  FROM actual_frame_timeline_slice
  WHERE android_is_app_jank_type(jank_type) = TRUE
)
GROUP BY process_name
ORDER BY SUM(dur) DESC;

In this more complex examples, join trace data that spans multiple tables to identify MessageQueue contention during app startup:

INCLUDE PERFETTO MODULE android.monitor_contention;
INCLUDE PERFETTO MODULE android.startup.startups;

-- Join package and process information for startups
DROP VIEW IF EXISTS startups;
CREATE VIEW startups AS
SELECT startup_id, ts, dur, upid
FROM android_startups
JOIN android_startup_processes USING(startup_id);

-- Intersect monitor contention with startups in the same process.
DROP TABLE IF EXISTS monitor_contention_during_startup;
CREATE VIRTUAL TABLE monitor_contention_during_startup
USING SPAN_JOIN(android_monitor_contention PARTITIONED upid, startups PARTITIONED upid);

SELECT
  process_name,
  SUM(dur) / 1000000 AS sum_dur_ms,
  COUNT(*) AS count_contention
FROM monitor_contention_during_startup
WHERE is_blocked_thread_main
AND short_blocked_method LIKE "%MessageQueue%"
GROUP BY process_name
ORDER BY SUM(dur) DESC;

You can use your favorite LLM to write PerfettoSQL queries to find other patterns.

At Google, we use BigTrace to run PerfettoSQL queries across millions of traces. In doing so, we confirmed that what we saw anecdotally was, in fact, a systemic issue. The data revealed that MessageQueue lock contention impacts users across the entire ecosystem, substantiating the need for a fundamental architectural change.

Solution: lock-free concurrency

We addressed the MessageQueue contention problem by implementing a lock-free data structure, using atomic memory operations rather than exclusive locks to synchronize access to shared state. A data structure or algorithm is lock-free if at least one thread can always make progress regardless of the scheduling behavior of the other threads. This property is generally hard to achieve, and is usually not worth pursuing for most code.

The atomic primitives

Lock-free software often relies on atomic Read-Modify-Write primitives that the hardware provides.

On older generation ARM64 CPUs, atomics used a Load-Link/Store-Conditional (LL/SC) loop. The CPU loads a value and marks the address. If another thread writes to that address, the store fails, and the loop retries. Because the threads can keep trying and succeed without waiting for another thread, this operation is lock-free.

ARM64 LL/SC loop example
retry:
    ldxr    x0, [x1]        // Load exclusive from address x1 to x0
    add     x0, x0, #1      // Increment value by 1
    stxr    w2, x0, [x1]    // Store exclusive.
                            // w2 gets 0 on success, 1 on failure
    cbnz    w2, retry       // If w2 is non-zero (failed), branch to retr

(view in Compiler Explorer)

Newer ARM architectures (ARMv8.1) support Large System Extensions (LSE) which include instructions in the form of Compare-And-Swap (CAS) or Load-And-Add (demonstrated below). In Android 17 we added support to the Android Runtime (ART) compiler to detect when LSE is supported and emit optimized instructions:

/ ARMv8.1 LSE atomic example
ldadd   x0, x1, [x2]    // Atomic load-add.
                        // Faster, no loop required.

In our benchmarks, high-contention code that uses CAS achieves a ~3x speedup over the LL/SC variant.

The Java programming language offers atomic primitives via java.util.concurrent.atomic that rely on these and other specialized CPU instructions.

The Data Structure: DeliQueue

To remove lock contention from MessageQueue, our engineers designed a novel data structure called DeliQueue. DeliQueue separates Message insertion from Message processing:

1. The list of Messages (Treiber stack): A lock-free stack. Any thread can push new Messages here without contention.

2. The priority queue (Min-heap): A heap of Messages to handle, exclusively owned by the Looper thread (hence no synchronization or locks are needed to access).

Enqueue: pushing to a Treiber stack

The list of Messages is kept in a Treiber stack [1], a lock-free stack that uses a CAS loop to update the head pointer.

public class TreiberStack <E> {
    AtomicReference<Node<E>> top =
            new AtomicReference<Node<E>>();
    public void push(E item) {
        Node<E> newHead = new Node<E>(item);
        Node<E> oldHead;
        do {
            oldHead = top.get();
            newHead.next = oldHead;
        } while (!top.compareAndSet(oldHead, newHead));
    }

    public E pop() {
        Node<E> oldHead;
        Node<E> newHead;
        do {
            oldHead = top.get();
            if (oldHead == null) return null;
            newHead = oldHead.next;
        } while (!top.compareAndSet(oldHead, newHead));
        return oldHead.item;
    }
}

Source code based on Java Concurrency in Practice [2], available online and released to the public domain

Any producer can push new Messages to the stack at any time. This is like pulling a ticket at a deli counter – your number is determined by when you showed up, but the order you get your food in doesn’t have to match. Because it’s a linked stack, every Message is a sub-stack – you can see what the Message queue was like at any point in time by tracking the head and iterating forwards – you won’t see any new Messages pushed on top, even if they’re being added during your traversal.

Dequeue: bulk transfer to a min-heap

To find the next Message to handle, the Looper processes new Messages from the Treiber stack by walking the stack starting from the top and iterating until it finds the last Message that it previously processed. As the Looper traverses down the stack, it inserts Messages into the deadline-ordered min-heap. Since the Looper exclusively owns the heap, it orders and processes Messages without locks or atomics.

In walking down the stack, the Looper also creates links from stacked Messages back to their predecessors, thus forming a doubly-linked list. Creating the linked list is safe because links pointing down the stack are added via the Treiber stack algorithm with CAS, and links up the stack are only ever read and modified by the Looper thread. These back links are then used to remove Messages from arbitrary points in the stack in O(1) time.

This design provides O(1) insertion for producers (threads posting work to the queue) and amortized O(log N) processing for the consumer (the Looper).

Using a min-heap to order Messages also addresses a fundamental flaw in the legacy MessageQueue, where Messages were kept in a singly-linked list (rooted at the top). In the legacy implementation, removal from the head was O(1), but insertion had a worst case of O(N) – scaling poorly for overloaded queues! Conversely, insertion to and removal from the min-heap scale logarithmically, delivering competitive average performance but really excelling in tail latencies.

In the legacy queue implementation, producers and the consumer used a lock to coordinate exclusive access to the underlying singly-linked list. In DeliQueue, the Treiber stack handles concurrent access, and the single consumer handles ordering its work queue.

Removal: consistency via tombstones

DeliQueue is a hybrid data structure, joining a lock-free Treiber stack with a single-threaded min-heap. Keeping these two structures in sync without a global lock presents a unique challenge: a message might be physically present in the stack but logically removed from the queue.

To solve this, DeliQueue uses a technique called “tombstoning.” Each Message tracks its position in the stack via the backwards and forwards pointers, its index in the heap’s array, and a boolean flag indicating whether it has been removed. When a Message is ready to run, the Looper thread will CAS its removed flag, then remove it from the heap and stack.

When another thread needs to remove a Message, it doesn’t immediately extract it from the data structure. Instead, it performs the following steps:

1. Logical removal: the thread uses a CAS to atomically set the Message’s removal flag from false to true. The Message remains in the data structure as evidence of its pending removal, a so-called “tombstone”. Once a Message is flagged for removal, DeliQueue treats it as if it no longer exists in the queue whenever it’s found.

2. Deferred cleanup: The actual removal from the data structure is the responsibility of the Looper thread, and is deferred until later. Rather than modifying the stack or heap, the remover thread adds the Message to another lock-free freelist stack.

3. Structural removal: Only the Looper can interact with the heap or remove elements from the stack. When it wakes up, it clears the freelist and processes the Messages it contained. Each Message is then unlinked from the stack and removed from the heap.

This approach keeps all management of the heap single-threaded. It minimizes the number of concurrent operations and memory barriers required, making the critical path faster and simpler.

Traversal: benign Java memory model data races

We perform an atomic read of the head, and see A. A’s next pointer points to B. At the same time as we process B, the looper might remove B and C, by updating A to point to C and then D.

Even though B and C are logically removed, B retains its next pointer to C, and C to D. The reading thread continues traversing through the detached removed nodes and eventually rejoins the live stack at D.

By designing DeliQueue to handle races between traversal and removal, we allow for safe, lock-free iteration.

Quitting: Native refcount

Looper is backed by a native allocation that must be manually freed once the Looper has quit. If some other thread is adding Messages while the Looper is quitting, it could use the native allocation after it’s freed, a memory safety violation. We prevent this using a tagged refcount, where one bit of the atomic is used to indicate whether the Looper is quitting.

Before using the native allocation, a thread reads the refcount atomic. If the quitting bit is set, it returns that the Looper is quitting and the native allocation must not be used. If not, it attempts a CAS to increment the number of active threads using the native allocation. After doing what it needs to, it decrements the count. If the quitting bit was set after its increment but before the decrement, and the count is now zero, then it wakes up the Looper thread.

When the Looper thread is ready to quit, it uses CAS to set the quitting bit in the atomic. If the refcount was 0, it can proceed to free its native allocation. Otherwise, it parks itself, knowing that it will be woken up when the last user of the native allocation decrements the refcount. This approach does mean that the Looper thread waits for the progress of other threads, but only when it’s quitting. That only happens once and is not performance sensitive, and it keeps the other code for using the native allocation fully lock-free.

There’s a lot of other tricks and complexity in the implementation. You can learn more about DeliQueue by reviewing the source code.

Optimization: branchless programming

While developing and testing DeliQueue, the team ran many benchmarks and carefully profiled the new code. One issue identified using the simpleperf tool was pipeline flushes caused by the Message comparator code.

A standard comparator uses conditional jumps, with the condition for deciding which Message comes first simplified below:

static int compareMessages(@NonNull Message m1, @NonNull Message m2) {
    if (m1 == m2) {
        return 0;
    }

    // Primary queue order is by when.
    // Messages with an earlier when should come first in the queue.
    final long whenDiff = m1.when - m2.when;
    if (whenDiff > 0) return 1;
    if (whenDiff < 0) return -1;

    // Secondary queue order is by insert sequence.
    // If two messages were inserted with the same `when`, the one inserted
    // first should come first in the queue.
    final long insertSeqDiff = m1.insertSeq - m2.insertSeq;
    if (insertSeqDiff > 0) return 1;
    if (insertSeqDiff < 0) return -1;

    return 0;
}

This code compiles to conditional jumps (b.le and cbnz instructions). When the CPU encounters a conditional branch, it can’t know whether the branch is taken until the condition is computed, so it doesn’t know which instruction to read next, and has to guess, using a technique called branch prediction. In a case like binary search, the branch direction will be unpredictably different at each step, so it’s likely that half the predictions will be wrong. Branch prediction is often ineffective in searching and sorting algorithms (such as the one used in a min-heap), because the cost of guessing wrong is larger than the improvement from guessing correctly. When the branch predictor guesses wrong, it must throw away the work it did after assuming the predicted value, and start again from the path that was actually taken – this is called a pipeline flush.

To find this issue, we profiled our benchmarks using the branch-misses performance counter, which records stack traces where the branch predictor guesses wrong. We then visualized the results with Google pprof, as shown below:

Recall that the original MessageQueue code used a singly-linked list for the ordered queue. Insertion would traverse the list in sorted order as a linear search, stopping at the first element that’s past the point of insertion and linking the new Message ahead of it. Removal from the head simply required unlinking the head. Whereas DeliQueue uses a min-heap, where mutations require reordering some elements (sifting up or down) with logarithmic complexity in a balanced data structure, where any comparison has an even chance of directing the traversal to a left child or to a right child. The new algorithm is asymptotically faster, but exposes a new bottleneck as the search code stalls on branch misses half the time.

Realizing that branch misses were slowing down our heap code, we optimized the code using branch-free programming:

// Branchless Logic
static int compareMessages(@NonNull Message m1, @NonNull Message m2) {
    final long when1 = m1.when;
    final long when2 = m2.when;
    final long insertSeq1 = m1.insertSeq;
    final long insertSeq2 = m2.insertSeq;

    // signum returns the sign (-1, 0, 1) of the argument,
    // and is implemented as pure arithmetic:
    // ((num >> 63) | (-num >>> 63))
    final int whenSign = Long.signum(when1 - when2);
    final int insertSeqSign = Long.signum(insertSeq1 - insertSeq2);

    // whenSign takes precedence over insertSeqSign,
    // so the formula below is such that insertSeqSign only matters
    // as a tie-breaker if whenSign is 0.
    return whenSign * 2 + insertSeqSign;
}

To understand the optimization, disassemble the two examples in Compiler Explorer and use LLVM-MCA, a CPU simulator that can generate an estimated timeline of CPU cycles.

The original code:
Index     01234567890123
[0,0]     DeER .    .  .   sub  x0, x2, x3
[0,1]     D=eER.    .  .   cmp  x0, #0
[0,2]     D==eER    .  .   cset w0, ne
[0,3]     .D==eER   .  .   cneg w0, w0, lt
[0,4]     .D===eER  .  .   cmp  w0, #0
[0,5]     .D====eER .  .   b.le #12
[0,6]     . DeE---R .  .   mov  w1, #1
[0,7]     . DeE---R .  .   b    #48
[0,8]     . D==eE-R .  .   tbz  w0, #31, #12
[0,9]     .  DeE--R .  .   mov  w1, #-1
[0,10]    .  DeE--R .  .   b    #36
[0,11]    .  D=eE-R .  .   sub  x0, x4, x5
[0,12]    .   D=eER .  .   cmp  x0, #0
[0,13]    .   D==eER.  .   cset w0, ne
[0,14]    .   D===eER  .   cneg w0, w0, lt
[0,15]    .    D===eER .   cmp  w0, #0
[0,16]    .    D====eER.   csetm        w1, lt
[0,17]    .    D===eE-R.   cmp  w0, #0
[0,18]    .    .D===eER.   csinc        w1, w1, wzr, le
[0,19]    .    .D====eER   mov  x0, x1
[0,20]    .    .DeE----R   ret

Note the one conditional branch, b.le,  which avoids comparing the insertSeq fields if the result is already known from comparing the when fields.

The branchless code:
Index     012345678
[0,0]     DeER .  .   sub       x0, x2, x3
[0,1]     DeER .  .   sub       x1, x4, x5
[0,2]     D=eER.  .   cmp       x0, #0
[0,3]     .D=eER  .   cset      w0, ne
[0,4]     .D==eER .   cneg      w0, w0, lt
[0,5]     .DeE--R .   cmp       x1, #0
[0,6]     . DeE-R .   cset      w1, ne
[0,7]     . D=eER .   cneg      w1, w1, lt
[0,8]     . D==eeER   add       w0, w1, w0, lsl #1
[0,9]     .  DeE--R   ret

Here, the branchless implementation takes fewer cycles and instructions than even the shortest path through the branchy code – it’s better in all cases. The faster implementation plus the elimination of mispredicted branches resulted in a 5x improvement in some of our benchmarks!

However, this technique is not always applicable. Branchless approaches generally require doing work that will be thrown away, and if the branch is predictable most of the time, that wasted work can slow your code down. In addition, removing a branch often introduces a data dependency. Modern CPUs execute multiple operations per cycle, but they can’t execute an instruction until its inputs from a previous instruction are ready. In contrast, a CPU can speculate about data in branches, and work ahead if a branch is predicted correctly.

Testing and Validation

Validating the correctness of lock-free algorithms is notoriously difficult!

In addition to standard unit tests for continuous validation during development, we also wrote rigorous stress tests to verify queue invariants and to attempt to induce data races if they existed. In our test labs we could run millions of test instances on emulated devices and on real hardware.

With Java ThreadSanitizer (JTSan) instrumentation, we could use the same tests to also detect some data races in our code. JTSan did not find any problematic data races in DeliQueue, but – surprisingly -actually detected two concurrency bugs in the Robolectric framework, which we promptly fixed.

To improve our debugging capabilities, we built new analysis tools. Below is an example showing an issue in Android platform code where one thread is overloading another thread with Messages, causing a large backlog, visible in Perfetto thanks to the MessageQueue instrumentation feature that we added.

To enable MessageQueue tracing in the system_server process, include the following in your Perfetto configuration:

data_sources {
  config {
    name: "track_event"
    target_buffer: 0  # Change this per your buffers configuration
    track_event_config {
      enabled_categories: "mq"
    }
  }
}

Impact

DeliQueue improves system and app performance by eliminating locks from MessageQueue.

• Synthetic benchmarks: multi-threaded insertions into busy queues is up to 5,000x faster than the legacy MessageQueue, thanks to improved concurrency (the Treiber stack) and faster insertions (the min-heap).

• In Perfetto traces acquired from internal beta testers, we see a reduction of 15% in app main thread time spent in lock contention.

• On the same test devices, the reduced lock contention leads to significant improvements to the user experience, such as:

• -4% missed frames in apps.

• -7.7% missed frames in System UI and Launcher interactions.

• -9.1% in time from app startup to the first frame drawn, at the 95%ile.

Next steps

DeliQueue is rolling out to apps in Android 17. App developers should review preparing your app for the new lock-free MessageQueue on the Android Developers blog to learn how to test their apps.

References

[1] Treiber, R.K., 1986. Systems programming: Coping with parallelism. International Business Machines Incorporated, Thomas J. Watson Research Center.

[2] Goetz, B., Peierls, T., Bloch, J., Bowbeer, J., Holmes, D., & Lea, D. (2006). Java Concurrency in Practice. Addison-Wesley Professional.

The post Under the hood: Android 17’s lock-free MessageQueue appeared first on InShot Pro.

Posted by Matthew McCullough, VP of Product Management, Android Developer

Today we’re releasing the first beta of Android 17, continuing our work to build a platform that prioritizes privacy, security, and refined performance. This build continues our work for more adaptable Android apps, introduces significant enhancements to camera and media capabilities, new tools for optimizing connectivity, and expanded profiles for companion devices. This release also highlights a fundamental shift in the way we’re bringing new releases to the developer community, from the traditional Developer Preview model to the Android Canary program

Beyond the Developer Preview

Android has replaced the traditional “Developer Preview” with a continuous Canary channel. This new “always-on” model offers three main benefits:

• Faster Access: Features and APIs land in Canary as soon as they pass internal testing, rather than waiting for a quarterly release.
• Better Stability: Early “battle-testing” in Canary results in a more polished Beta experience with new APIs and behavior changes that are closer to being final.
• Easier Testing: Canary supports OTA updates (no more manual flashing) and, as a separate update channel, more easily integrates with CI workflows and gives you the earliest window to give immediate feedback on upcoming potential changes.

The Android 17 schedule

We’re going to be moving quickly from this Beta to our Platform Stability milestone, targeted for March. At this milestone, we’ll deliver final SDK/NDK APIs and largely final app-facing behaviors. From that time you’ll have several months before the final release to complete your testing.

A year of releases

We plan for Android 17 to continue to get updates in a series of quarterly releases. The upcoming release in Q2 is the only one where we introduce planned app breaking behavior changes. We plan to have a minor SDK release in Q4 with additional APIs and features.

Orientation and resizability restrictions

With the release of the Android 17 Beta, we’re moving to the next phase of our adaptive roadmap: Android 17 (API level 37) removes the developer opt-out for orientation and resizability restrictions on large screen devices (sw > 600 dp).

When your app targets SDK 37, it must be ready to adapt. Users expect their apps to work everywhere—whether multitasking on a tablet, unfolding a device, or using a desktop windowing environment—and they expect the UI to fill the space and respect their device posture.

Key Changes for SDK 37

Apps targeting Android 17 must ensure compatibility with the phase-out of manifest attributes and runtime APIs introduced in Android 16. When running on a large screen (smaller dimension ≥ 600dp), the following attributes and APIs will be ignored:

Manifest attributes/API	Ignored values
screenOrientation	portrait, reversePortrait, sensorPortrait, userPortrait, landscape, reverseLandscape, sensorLandscape, userLandscape
setRequestedOrientation()	portrait, reversePortrait, sensorPortrait, userPortrait, landscape, reverseLandscape, sensorLandscape, userLandscape
resizeableActivity	all
minAspectRatio	all
maxAspectRatio	all

Exemptions and User Control

These changes are specific to large screens; they do not apply to screens smaller than sw600dp (including traditional slate form factor phones). Additionally, apps categorized as games (based on the android:appCategory flag) are exempt from these restrictions.

It is also important to note that users remain in control. They can explicitly opt-in/out to using an app’s default behavior via the system’s aspect ratio settings.

Updates to configuration changes

To improve app compatibility and help minimize interrupted video playback, dropped input, and other types of disruptive state loss, we are updating the default behavior for Activity recreation. Starting with Android 17, the system will no longer restart activities by default for specific configuration changes that typically do not require a UI recreation, including CONFIG_KEYBOARD, CONFIG_KEYBOARD_HIDDEN, CONFIG_NAVIGATION, CONFIG_UI_MODE (when only UI_MODE_TYPE_DESK is changed), CONFIG_TOUCHSCREEN, and CONFIG_COLOR_MODE. Instead, running activities will simply receive these updates via onConfigurationChanged. If your application relies on a full restart to reload resources for these changes, you must now explicitly opt-in using the new android:recreateOnConfigChanges manifest attribute, which allows you to specify which configuration changes should trigger a complete activity lifecycle (from stop, to destroy and creation again), together with the related constants mcc, mnc, and the new ones keyboard, keyboardHidden, navigation, touchscreen and colorMode.

Prepare Your App

We’ve released tools and documentation to make it easy for you. Our focused blog post has more guidance, with strategies to address common issues. Apps will need to support landscape and portrait layouts for window sizes across the full range of aspect ratios, as restricting orientation or aspect ratio will no longer be an option. We recommend testing your app using the Android 17 Beta 1 with Pixel Tablet or Pixel Fold emulators (configured to targetSdkPreview = “CinnamonBun”) or by using the app compatibility framework to enable UNIVERSAL_RESIZABLE_BY_DEFAULT on Android 16 devices.

Performance

Lock-free MessageQueue

In Android 17, apps targeting SDK 37 or higher will receive a new implementation of android.os.MessageQueue where the implementation is lock-free. The new implementation improves performance and reduces missed frames, but may break clients that reflect on MessageQueue private fields and methods.

Generational garbage collection

Android 17 introduces generational garbage collection to ART‘s Concurrent Mark-Compact collector. This optimization introduces more frequent, less resource-intensive young-generation collections alongside full-heap collections. aiming to reduce overall garbage collection CPU cost and time duration. ART improvements are also available to over a billion devices running Android 12 (API level 31) and higher through Google Play System updates.

Static final fields now truly final

Starting from Android 17 apps targeting Android 17 or later won’t be able to modify “static final” fields, allowing the runtime to apply performance optimizations more aggressively. An attempt to do so via reflection (and deep reflection) will always lead to IllegalAccessException being thrown. Modifying them via JNI’s SetStatic<Type>Field methods family will immediately crash the application.

Custom Notification View Restrictions

To reduce memory usage we are restricting the size of custom notification views. This update closes a loophole that allows apps to bypass existing limits using URIs. This behavior is gated by the target SDK version and takes effect for apps targeting API 37 and higher.

New performance debugging ProfilingManager triggers

We’ve introduced several new system triggers to ProfilingManager to help you collect in-depth data to debug performance issues. These triggers are TRIGGER_TYPE_COLD_START, TRIGGER_TYPE_OOM, and TRIGGER_TYPE_KILL_EXCESSIVE_CPU_USAGE.

To understand how to set up the new system triggers, check out the trigger-based profiling and retrieve and analyze profiling data documentation.

Media and Camera

Android 17 brings professional-grade tools to media and camera apps, with features like seamless transitions and standardized loudness.

Dynamic Camera Session Updates

We have introduced updateOutputConfigurations() to CameraCaptureSession. This allows you to dynamically attach and detach output surfaces without the need to reconfigure the entire camera capture session. This change enables seamless transitions between camera use cases and modes (such as shooting still images vs shooting videos) without the memory cost and code complexity of configuring and holding onto all camera output surfaces that your app might need during camera start up. This helps to eliminate user-visible glitches or freezes during operation.

fun updateCameraSession(session: CameraCaptureSession, newOutputConfigs:  List<OutputConfiguration>)) {
    // Dynamically update the session without closing and reopening
    try {

        // Update the output configurations
        session.updateOutputConfigurations(newOutputConfigs)
    } catch (e: CameraAccessException) {
        // Handle error
    }
}

Logical multi-camera device metadata

When working with logical cameras that combine multiple physical camera sensors, you can now request additional metadata from all active physical cameras involved in a capture, not just the primary one. Previously, you had to implement workarounds, sometimes allocating unnecessary physical streams, to obtain metadata from secondary active cameras (e.g., during a lens switch for zoom where a follower camera is active). This feature introduces a new key, LOGICAL_MULTI_CAMERA_ADDITIONAL_RESULTS, in CaptureRequest and CaptureResult. By setting this key to ON in your CaptureRequest, the TotalCaptureResult will include metadata from these additional active physical cameras. You can access this comprehensive metadata using TotalCaptureResult.getPhysicalCameraTotalResults() to get more detailed information that may enable you to optimize resource usage in your camera applications.

Versatile Video Coding (VVC) Support

Android 17 adds support for the Versatile Video Coding (VVC) standard. This includes defining the video/vvc MIME type in MediaFormat, adding new VVC profiles in MediaCodecInfo, and integrating support into MediaExtractor. This feature will be coming to devices with hardware decode support and capable drivers.

Constant Quality for Video Recording

We have added setVideoEncodingQuality() to MediaRecorder. This allows you to configure a constant quality (CQ) mode for video encoders, giving you finer control over video quality beyond simple bitrate settings.

Background Audio Hardening

Starting in Android 17, the audio framework will enforce restrictions on background audio interactions including audio playback, audio focus requests, and volume change APIs to ensure that these changes are started intentionally by the user.

If the app tries to call audio APIs while the application is not in a valid lifecycle, the audio playback and volume change APIs will fail silently without an exception thrown or failure message provided. The audio focus API will fail with the result code AUDIOFOCUS_REQUEST_FAILED.

Privacy and Security

Deprecation of Cleartext Traffic Attribute

The android:usesCleartextTraffic attribute is now deprecated. If your app targets (Android 17) or higher and relies on usesCleartextTraffic=”true” without a corresponding Network Security Configuration, it will default to disallowing cleartext traffic. You are encouraged to migrate to Network Security Configuration files for granular control.

HPKE Hybrid Cryptography

We are introducing a public Service Provider Interface (SPI) for an implementation of HPKE hybrid cryptography, enabling secure communication using a combination of public key and symmetric encryption (AEAD).

Connectivity and Telecom

Enhanced VoIP Call History

We are introducing user preference management for app VoIP call history integration. This includes support for caller and participant avatar URIs in the system dialer, enabling granular user control over call log privacy and enriching the visual display of integrated VoIP call logs.

Wi-Fi Ranging and Proximity

Wi-Fi Ranging has been enhanced with new Proximity Detection capabilities, supporting continuous ranging and secure peer-to-peer discovery. Updates to Wi-Fi Aware ranging include new APIs for peer handles and PMKID caching for 11az secure ranging.

Developer Productivity and Tools

Updates for companion device apps

We have introduced two new profiles to the CompanionDeviceManager to improve device distinction and permission handling:

• Medical Devices: This profile allows medical device mobile applications to request all necessary permissions with a single tap, simplifying the setup process.

• Fitness Trackers: The DEVICE_PROFILE_FITNESS_TRACKER profile allows companion apps to explicitly indicate they are managing a fitness tracker. This ensures accurate user experiences with distinct icons while reusing existing watch role permissions.

Also, the CompanionDeviceManager now offers a unified dialog for device association and Nearby permission requests. You can leverage the new setExtraPermissions method in AssociationRequest.Builder to bundle nearby permission prompts within the existing association flow, reducing the number of dialogs presented to the user.

Get started with Android 17

You can enroll any supported Pixel device to get this and future Android Beta updates over-the-air. If you don’t have a Pixel device, you can use the 64-bit system images with the Android Emulator in Android Studio.

If you are currently in the Android Beta program, you will be offered an over-the-air update to Beta 1.

If you have Android 26Q1 Beta and would like to take the final stable release of 26Q1 and exit Beta, you need to ignore the over-the-air update to 26Q2 Beta 1 and wait for the release of 26Q1.

We’re looking for your feedback so please report issues and submit feature requests on the feedback page. The earlier we get your feedback, the more we can include in our work on the final release.

For the best development experience with Android 17, we recommend that you use the latest preview of Android Studio (Panda). Once you’re set up, here are some of the things you should do:

• Compile against the new SDK, test in CI environments, and report any issues in our tracker on the feedback page.

• Test your current app for compatibility, learn whether your app is affected by changes in Android 17, and install your app onto a device or emulator running Android 17 and extensively test it.

We’ll update the preview/beta system images and SDK regularly throughout the Android 17 release cycle. Once you’ve installed a beta build, you’ll automatically get future updates over-the-air for all later previews and Betas.

For complete information, visit the Android 17 developer site.

Join the conversation

As we move toward Platform Stability and the final stable release of Android 17 later this year, your feedback remains our most valuable asset. Whether you’re an early adopter on   the Canary channel or an app developer testing on Beta 1, consider joining our communities and filing feedback. We’re listening.

The post The First Beta of Android 17 appeared first on InShot Pro.

Posted by Roxanna Aliabadi Walker, Product Manager and Yacine Rezgui, Developer Relations Engineer

The Embedded Photo Picker: A more seamless way to privately request photos and videos in your app

Get ready to enhance your app’s user experience with an exciting new way to use the Android photo picker! The new embedded photo picker offers a seamless and privacy-focused way for users to select photos and videos, right within your app’s interface. Now your app can get all the same benefits available with the photo picker, including access to cloud content, integrated directly into your app’s experience.

Why embedded?

We understand that many apps want to provide a highly integrated and seamless experience for users when selecting photos or videos. The embedded photo picker is designed to do just that, allowing users to quickly access their recent photos without ever leaving your app. They can also explore their full library in their preferred cloud media provider (e.g., Google Photos), including favorites, albums and search functionality. This eliminates the need for users to switch between apps or worry about whether the photo they want is stored locally or in the cloud.

Seamless integration, enhanced privacy

With the embedded photo picker, your app doesn’t need access to the user’s photos or videos until they actually select something. This means greater privacy for your users and a more streamlined experience. Plus, the embedded photo picker provides users with access to their entire cloud-based media library, whereas the standard photo permission is restricted to local files only.

The embedded photo picker in Google Messages

Google Messages showcases the power of the embedded photo picker. Here’s how they’ve integrated it:

• Intuitive placement: The photo picker sits right below the camera button, giving users a clear choice between capturing a new photo or selecting an existing one.
• Dynamic preview: Immediately after a user taps a photo, they see a large preview, making it easy to confirm their selection. If they deselect the photo, the preview disappears, keeping the experience clean and uncluttered.
• Expand for more content: The initial view is simplified, offering easy access to recent photos. However, users can easily expand the photo picker to browse and choose from all photos and videos in their library, including cloud content from Google Photos.
• Respecting user choices: The embedded photo picker only grants access to the specific photos or videos the user selects, meaning they can stop requesting the photo and video permissions altogether. This also saves the Messages from needing to handle situations where users only grant limited access to photos and videos.

Implementation

Integrating the embedded photo picker is made easy with the Photo Picker Jetpack library.

Jetpack Compose

First, include the Jetpack Photo Picker library as a dependency.

implementation("androidx.photopicker:photopicker-compose:1.0.0-alpha01")

The EmbeddedPhotoPicker composable function provides a mechanism to include the embedded photo picker UI directly within your Compose screen. This composable creates a SurfaceView which hosts the embedded photo picker UI. It manages the connection to the EmbeddedPhotoPicker service, handles user interactions, and communicates selected media URIs to the calling application.

@Composable
fun EmbeddedPhotoPickerDemo() {
    // We keep track of the list of selected attachments
    var attachments by remember { mutableStateOf(emptyList<Uri>()) }

    val coroutineScope = rememberCoroutineScope()
    // We hide the bottom sheet by default but we show it when the user clicks on the button
    val scaffoldState = rememberBottomSheetScaffoldState(
        bottomSheetState = rememberStandardBottomSheetState(
            initialValue = SheetValue.Hidden,
            skipHiddenState = false
        )
    )

    // Customize the embedded photo picker
    val photoPickerInfo = EmbeddedPhotoPickerFeatureInfo
        .Builder()
        // Set limit the selection to 5 items
        .setMaxSelectionLimit(5)
        // Order the items selection (each item will have an index visible in the photo picker)
        .setOrderedSelection(true)
        // Set the accent color (red in this case, otherwise it follows the device's accent color)
        .setAccentColor(0xFF0000)
        .build()

    // The embedded photo picker state will be stored in this variable
    val photoPickerState = rememberEmbeddedPhotoPickerState(
        onSelectionComplete = {
            coroutineScope.launch {
                // Hide the bottom sheet once the user has clicked on the done button inside the picker
                scaffoldState.bottomSheetState.hide()
            }
        },
        onUriPermissionGranted = {
            // We update our list of attachments with the new Uris granted
            attachments += it
        },
        onUriPermissionRevoked = {
            // We update our list of attachments with the Uris revoked
            attachments -= it
        }
    )

       SideEffect {
        val isExpanded = scaffoldState.bottomSheetState.targetValue == SheetValue.Expanded

        // We show/hide the embedded photo picker to match the bottom sheet state
        photoPickerState.setCurrentExpanded(isExpanded)
    }

    BottomSheetScaffold(
        topBar = {
            TopAppBar(title = { Text("Embedded Photo Picker demo") })
        },
        scaffoldState = scaffoldState,
        sheetPeekHeight = if (scaffoldState.bottomSheetState.isVisible) 400.dp else 0.dp,
        sheetContent = {
            Column(Modifier.fillMaxWidth()) {
                // We render the embedded photo picker inside the bottom sheet
                EmbeddedPhotoPicker(
                    state = photoPickerState,
                    embeddedPhotoPickerFeatureInfo = photoPickerInfo
                )
            }
        }
    ) { innerPadding ->
        Column(Modifier.padding(innerPadding).fillMaxSize().padding(horizontal = 16.dp)) {
            Button(onClick = {
                coroutineScope.launch {
                    // We expand the bottom sheet, which will trigger the embedded picker to be shown
                    scaffoldState.bottomSheetState.partialExpand()
                }
            }) {
                Text("Open photo picker")
            }
            LazyVerticalGrid(columns = GridCells.Adaptive(minSize = 64.dp)) {
                // We render the image using the Coil library
                itemsIndexed(attachments) { index, uri ->
                    AsyncImage(
                        model = uri,
                        contentDescription = "Image ${index + 1}",
                        contentScale = ContentScale.Crop,
                        modifier = Modifier.clickable {
                            coroutineScope.launch {
                                // When the user clicks on the media from the app's UI, we deselect it
                                // from the embedded photo picker by calling the method deselectUri
                                photoPickerState.deselectUri(uri)
                            }
                        }
                    )
                }
            }
        }
    }
}

Views

First, include the Jetpack Photo Picker library as a dependency.

implementation("androidx.photopicker:photopicker:1.0.0-alpha01")

To add the embedded photo picker, you need to add an entry to your layout file.

<view class="androidx.photopicker.EmbeddedPhotoPickerView"
    android:id="@+id/photopicker"
    android:layout_width="match_parent"
    android:layout_height="match_parent" />

And initialize it in your activity/fragment.

// We keep track of the list of selected attachments
private val _attachments = MutableStateFlow(emptyList<Uri>())
val attachments = _attachments.asStateFlow()

private lateinit var picker: EmbeddedPhotoPickerView
private var openSession: EmbeddedPhotoPickerSession? = null

val pickerListener = object EmbeddedPhotoPickerStateChangeListener {
    override fun onSessionOpened (newSession: EmbeddedPhotoPickerSession) {
        openSession = newSession
    }

    override fun onSessionError (throwable: Throwable) {}

    override fun onUriPermissionGranted(uris: List<Uri>) {
        _attachments += uris
    }

    override fun onUriPermissionRevoked (uris: List<Uri>) {
        _attachments -= uris
    }

    override fun onSelectionComplete() {
        // Hide the embedded photo picker as the user is done with the photo/video selection
    }
}

override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    setContentView(R.layout.main_view)

    //
    // Add the embedded photo picker to a bottom sheet to allow the dragging to display the full photo library
    //

    picker = findViewById(R.id.photopicker)
    picker.addEmbeddedPhotoPickerStateChangeListener(pickerListener)
    picker.setEmbeddedPhotoPickerFeatureInfo(
        // Set a custom accent color
        EmbeddedPhotoPickerFeatureInfo.Builder().setAccentColor(0xFF0000).build()
    )
}

You can call different methods of EmbeddedPhotoPickerSession to interact with the embedded picker.

// Notify the embedded picker of a configuration change
openSession.notifyConfigurationChanged(newConfig)

// Update the embedded picker to expand following a user interaction
openSession.notifyPhotoPickerExpanded(/* expanded: */ true)

// Resize the embedded picker
openSession.notifyResized(/* width: */ 512, /* height: */ 256)

// Show/hide the embedded picker (after a form has been submitted)
openSession.notifyVisibilityChanged(/* visible: */ false)

// Remove unselected media from the embedded picker after they have been
// unselected from the host app's UI
openSession.requestRevokeUriPermission(removedUris)

It’s important to note that the embedded photo picker experience is available for users running Android 14 (API level 34) or higher with SDK Extensions 15+. Read more about photo picker device availability.

For enhanced user privacy and security, the system renders the embedded photo picker in a way that prevents any drawing or overlaying. This intentional design choice means that your UX should consider the photo picker’s display area as a distinct and dedicated element, much like you would plan for an advertising banner.

If you have any feedback or suggestions, submit tickets to our issue tracker.

The post The Embedded Photo Picker appeared first on InShot Pro.
